Label applicable: adhesive labels; adhesive films; electronic supervision code, bar code etc.
The clever design which allow user to mechanically adjust some structure combination and label winding,
makes it easy to adjust the labeling position freely (it can be fixed easily after adjustment). All these make the change of different products and winding of labels more simple and saving time.
Labeling Machines Features
Labeling machine produced accordance CE certificated.
Automatic Labeling with container for bottle feeding, labor and space saved.
Simple operation, labeling controlled by PLC and touch screen.
No products, No labeling, Brand Named Sensors applied, Labeling Accuracy is high.
Strong S/S frame construction.
Work independently or connected to a production line.
High Speed Labeling, suitable for big batch production.
Workflow:
auto feeding products
The sensor detect the products
auto labeling
Options Function for the Labeling Machine
Coder Printer to print batch number, expiry date and so on on the label when labeling
Clear Label sensor for round labeling
Remote control function is available
Parameter:
Speed
2400-4800 bph (related to product size)
Labeling accuracy
+/- 1mm
Products applicable
9mm≤D≤25mm, Height≤150mm (customizable)
labels applicable
adhesive stickers/opaque or transparent 10mm
Power supply
220V 50/60hz 1kw
Application
Round or cylindrical bottle labeling, tube labeling
