Automatic Linear Capping Machine with Cap Feeder

Description

Application

Used for Linear Packaging line for all kinds of Screw Caps, automatically feeding caps and capping

Automatically Linear Capping Pump Caps, but need Manual Feeding
Not applicable for tamper-proof caps

Capping Machine Features

Automatic Feeding Caps with Feeding Plate and Feeding Track
Turn Table for bottles feeding
Automatic Linear Capping for all kinds of caps
High Speed Capping

Workflow:

1)Manually put bottles on the conveyor
2)Automatic feeding caps from lift machine or vibration plate
3)Bottles conveyed to capping machine to screw/press cap automatically
4)Collect bottles with a turn table(optional)

Parameter:

Speed	1800-9000 bph (customizable)
Capping accuracy	＞99%
Caps applicable	Screw Caps
Caps' diameter range	12-70mm (can be customized)
Power supply	220V 50hz 2kw
Air supply	0.6MPa
Bottle applicable	35≤diameter≤140mm; 30≤height≤300mm
Caps feeding device	Lifter, vibration bowel, by hand
Feature	High speed
